TCH Concrete Weighbridge | Truck Scale

Robust TCH concrete weighbridge made of I beams structure, for 10 years warranty, installed with OIML approved load cells.

General Details

H beams Module Structure
Stronger H beams structure, with steel bars
Modules design for easy loading in truck or container

Concrete Platform*
Longer time for operation, not worry of rust any more
With adjusting cabinet *
concrete not included in the shipping list

Side Guide
Big H beams 500×200 as side guide

PLATFORM
Structure designed with H beams. Modules design for container/truck load. Width of 3m or 3.4m option. Length from 16m to 24m*. Big side guide of H beams 500×200. * other length customized demand * concrete not included in the shipping list.

LOAD CELL
OIML approved M36i column load cell. Stainless steel material. Hermetically sealed,IP68. Optional HM9B models.

INDICATOR
S.S housing, IP65 protection. 240×128 dot matrix LCD. High accuracy up to 10,000e. Anti-vibration and anti-surge design. Easy to operation wtith big LCD display. Multi interface: RS232, RS485, Erthernet, etc. Super anti-interference technology: Analog or digital working mode.

Models

Part No.410031410032410033410034
ModelsTCH316TCH318TCH321TCH324
Capacity80Ton100Ton100Ton120Ton
Division20kg20kg20kg20kg
Platform size3x16m3x18m3x21m3x24m



Part No.410035410036410037410038
ModelsTCH3416TCH3418TCH3421TCH3424
Capacity80Ton100Ton100Ton120Ton
Division20kg20kg20kg20kg
Platform size3.4x16m3.4x18m3.4x21m3.4x24m



Techical Info

POWER
100-240V (50-60Hz)

PLATFORM SIZE
Width – 3m or 3.4m
Length – 16 to 24m

CAPACITY
80t – 120t

ACCURACY
20kg

UNITS
Kg, t

OUTPUT
RS232
RS485
RJ45 (optional)
SD card (optional)

COMMUNICATION
Continous
Print
Modbus-RTU
Modbus-TCP

Order Enquiry

Contact form description text

  • 9 + 56 =
Approvals

OIML
